◀ Planer & moulder Kupfermühle DOMA-G
Technical details
ID: MS264
| Year: | 1975 |
| Working width: | 2050 mm |
| Working height: | 300 mm |
| Working height 4-side: | 300 mm |
| Number of spindles: | 6 |
| Spindle configuration: | 2 x bottom - 2 x top + left + right |
| Spindle diameter: | X-X-X-X-40-40 m m |
| Motor power: | 18,5-18,5-22-22-11-11 kW |
| Working width adjustments: | manuell |
| Working height adjustments: | elektrisch |
| Feed speed: | 26 m/min |
| Feed motor: | 5,5 kW |
| Driven bed rollers: | 2 |
| Infeed rollers: | 2 |
| Tools vertical: | 140 x 300 x 40 |
| Turning unit: | for curved beams |
| Extraction socket diameter: | 300-200-200-140-140 mm |
| Weight: | 7000 kg |
| Dimensions: | 3400x2500x2300 mm |
| Voltage: | 380V 50Hz 3Ph |
