◀ Planer & moulder Kupfermühle KH-30
Technical details
ID: MS229
| Year: | 1988 |
| Working width: | 300 mm |
| Working height: | 250 mm |
| Working height 4-side: | 100 mm |
| Number of spindles: | 5 |
| Spindle configuration: | b-t-r+l |
| Spindle diameter: | 40-60-60-40-40 m m |
| Jointer for spindle: | 1-2 |
| Motor power: | 11-22-37-11-11 kW |
| Working width adjustments: | manuell |
| Working height adjustments: | motorized |
| Feed speed: | 20-150 m/min |
| Feed motor: | 15 kW |
| Feed-system: | Cardan |
| Driven bed rollers: | 3 |
| Infeed rollers: | 3 |
| Outfeed rollers: | 1 |
| Tools horizontal: | 200x300x60 Z10 |
| Constant table height: | ca. 900 mm |
| Chip removal bottom: | 15 mm |
| Chip removal top: | 20 mm |
| Extraction socket diameter: | 120-200-200-120-120 mm |
| Weight: | 6000 kg |
| Dimensions: | 4000 x 1700 x 2050 mm |
| Voltage: | 380V 50Hz 3Ph. |
| inkl. Ritzsäge von oben, pneumatisch verstellbar über Pedal zum Einsägen der Entspannungsnut. incl. top scoring saw with | |
